CFAG19264D-YYH-VN

192x64 Graphic LCD, RoHS Compliant, Yellow/Green LED Backlight, STN Positive, Yellow/Green, Transflective -20°C to +70°C 6:00 viewing angle. Negative Voltage Generator

General
Tech Specs
Docs / Files
Notices
Dimensions
Related
Photos

CFAG19264D Graphic LCDs Family

192x64 graphic LCD module
Available in several variations of backlight and polarizer (minimum order may be required)
Wide temperature range: -20°C to 70°C (-4°F to 158°F)
Built-in controller: Samsung KS0107/KS0108
Demonstration board available here: CFA-10006
RoHS Compliant

For reference only. For design purposes, please use the specifications in the datasheet.

Physical Characteristics

Column Dots x Row Dots

192 x 64

Module Overall
	width	height	depth
millimeters	120	62	12.9
inches	4	2	0.5

PCB Outline
	width	height	depth
millimeters	120	62	12.9
inches	4	2	0.5

Viewing Area
	width	height
millimeters	102	39
inches	4	1

Active Area
	width	height
millimeters	96	32
inches	3	1

Dot Size
	width	height
millimeters	0.46	0.46
inches	0.01	0.01

Dot Pitch
	width	height
millimeters	0.5	0.5
inches	0.0	0.0

Weight

93g

Optical Characteristics

Display Technology	LCD
Display Addressing	passive
Glass Type/Glass Color	STN/Yellow-Green
Polarizer	Transflective
View Direction	6:00

Backlight Color	Yellow-Green
Backlight Type	LED
Mode	Positive
Foreground Color	Dark
Background Color	Yellow-Green

Electrical Specifications

Module Connector Pitch

0.10mm

Environmental

Operating Temperatures
	min	max
Celsius	-20°	70°
Farenheit	-4°	158°

Storage Temperatures
	min	max
Celsius	-30°	80°
Farenheit	-22°	176°

Humidity
	min	max
Non-condensing	0%	90%

Electronics

Controller	KS0107/KS0108 Compatible
Interface	8-bit Parallel

Datasheets

CFAG19264DYYHVN.pdf (361KB, May 2009)

Other Files

CAD Export - CFAG19264D-TFH-TMI-YYH_2D_CAD (649KB)
1 to 1 Template - CFAG19264D-TFH-TMI-YYH._1_TO_1.PDF (39KB)

Subscribe to Part Change Notices by email or RSS

No notices have been issued for this part.
