The CFA633 series of advanced display modules will be changing from the current firmware v2.1 to v2.2. Design changes were made for backwards compatibility.
As part of our continuous improvement, firmware has been updated for use with updated hardware for the CFA633 series of advanced display modules.
Command 1 (0x01): Get Hardware & Firmware Version
This command will now report the following strings
Serial versions (-KS suffix): "CFA633:h2.1,s2v2"
USB version (-KU suffix): "CFA633:h2.1,u2v2"
CFA633 firmware version 2.2 is considered a fit and form replacement. Testing of new firmware is recommended when the new hardware version 2.1 is available.
CFA633 hardware v2.1 is scheduled to begin shipping Q1 2017 after current inventory of hardware v2.0 is depleted following FIFO standards. Engineering samples for testing / validation will be available during this same time frame.
No price change is currently scheduled.
Part Change Notice #10729: CFA633 series Hardware revision 2.0 to 2.1
The CFA633 series of advanced display modules will be changing from the current hardware v2.0 to v2.1. Design changes were made for backwards compatibility.
As part of our continuous improvement, design changes have been made to the hardware of the CFA633 series of advanced display modules for improved manufacturability, improved quality, and a lower current profile.
Factory default configuration has no functional changes. Standard and custom configurations are not affected by the new hardware layout. CFA633 hardware version 2.1 should replace previous version of the CFA633 with no physical changes and is considered a fit and form replacement.
Six 0 ohm resistors have been added as factory default for closing the following jumpers:
JPGPIO -> RJPGPIO
JP8 -> RJP8
JP2 -> RJP2
JP4 -> RJP4
JP6 -> RJP6
JP8 -> RJP8
-KU builds only:
JPUSBPER -> RJPUSBPWR
Solder jumper are still in place for configuration after jumper resistor removed. Jumpers will appear open. Configuration changes not performed by Crystalfontz America, Inc. will need to make note of this manufacturing change.
CFA633 hardware version 2.1 is considered a fit and form replacement. Testing of new hardware is recommended when available.
CFA633 hardware v2.1 is scheduled to begin shipping Q1 2017 after current inventory of HW v2.0 is depleted following FIFO standards. Engineering samples for testing / validation will be available during this same time frame.
No price change is currently scheduled.
Part Change Notice #10658: Deprecation of "Drive Bay Kit Configurator" / New part numbers for drive bay kits.
Deprecation of "Drive Bay Kit Configurator" / New part numbers for drive bay kits.
Starting August 1, 2015 the "Drive Bay Kit Configurator" located at https://www.crystalfontz.com/products/select_kit.html will no longer be functional for ordering one of our Serial or USB displays (CFA533, CFA631, CFA632, CFA633, CFA634, CFA635, and CFA735) in a bracket or SLED. This functionality is being moved to the Customize and Add to Cart process when checking out. This will allow for further customization by our customers to better fit their needs.
This change will eliminate the current "kits", but will add options not previously available such as pre-configured ATX functionality, and ALL the currently available interfaces will be orderable in a drive bay bracket or SLED.
The new part numbers will have the bracket / SLED and overlay type as a PREFIX to the configured part number. The choice for bracket / SLED to a display order will be via the cart options. Our CFA835 displays were introduced with these configuration options.
To see how the new options will look, and what the new part numbers will look like, please see one of our CFA835 parts: https://www.crystalfontz.com/cart/addtocart.php?product_id=2277&qty=1
NOTE: The SLED is only available for the CFA635, CFA735, and CFA835 products.
As part of our continuous improvement process, we are integrating the ordering of displays in drive bay and SLED kits as part of the display ordering process.
Drive bay kits in their current configuration will no longer be available.
Place orders prior to 2015-08-01 for upcoming production needs via our website or by contacting our logistics department via email: firstname.lastname@example.org, or by calling 1-888-206-9720 (International call +1-509-892-1200).
After the 2015-08-01, please contact our engineering department via email@example.com to assist you with ordering your bracket / SLED kits.
Starting 2015-08-01, the bracket and SLED options for our serial and USB display will be part of the ordering process for the displays
Pricing bracket / SLED configurations will reflect manufacturing costs.
Technical Bulletin TB01: Comparison of CFA533 and CFA633 Modules by Version Number
The attached PDF file describes differences between our CFA633 v1.5x and CFA633 v2.0 intelligent display module series. We also list the CFA533 series as a comparison for customers who do not require the fan control available in the CFA633 series. Hardware version numbers are silk screened on the back of the PCBs.
Additional information can be found in supporting documents for PCN:
We will be phasing in the CFA-633 hardware version v1.5c over the next few months as the inventory of v1.5a modules is exhausted.
The currently shipping version of the CFA-633 hardware is v1.5a.
Here is a list of the changes between v1.5a and v1.5c:
* Changed from black painted steel plated bezel to stainless steel bezel. Your front panel bezel should hide the bezel, so this change should not affect the appearance of your product. If your product design exposes part of the CFA-633's black bezel, that area will now show as stainless steel.
* Increased keep-out clearance on PCB around the mounting holes.
* Minor PCB layout changes.
* Some factory configuration jumpers have changed.
