The Lowest of the Low Power
Do you need a display that draws the lowest current possible? Want long lasting battery-powered LCD project? Well, you have come to the right place. We compiled this list of digital displays that consume the least amount of power. These displays are perfect for when you are trying to extend the battery life of your product by pulling the least amount of current possible.
Low Power ePaper
Other than a pen and paper, ePaper provides the lowest power consumption available for electronic displays. It does this via an electrochemical process that requires zero power once the pixels are in their desired location. These displays are ideal for when the content is not updated very often. Low-power ePapers only use power during updates, so the longer time between updates, the lower the power consumed.
A selection of our ePapers is below, or browse all our ePaper displays.
- Part #: CFAP200200A50154
- Size: 31.8mm x 37.32mm x 1.05mm
- Interfaces: SPI
- Resolution: 200x200 pixels
- Diagonal Dimension: 1.5"
- Pin Count: 24
- Part #: CFAP152152C00154
- Size: 31.8mm x 37.32mm x 0.98mm
- Interfaces: SPI
- Resolution: 152x152 pixels
- Diagonal Dimension: 1.53"
- Pin Count: 24
- Part #: CFAP122250A20213
- Size: 29.2mm x 59.2mm x 1mm
- Interfaces: SPI
- Resolution: 122x250 pixels
- Diagonal Dimension: 2.13"
- Pin Count: 24
- Part #: CFAP128296C00290
- Size: 36.7mm x 79mm x 1.18mm
- Interfaces: SPI
- Resolution: 128x296 pixels
- Diagonal Dimension: 2.87"
- Pin Count: 24
- Part #: CFAP104212D10213
- Size: 29.2mm x 59.2mm x 0.3mm
- Interfaces: SPI
- Resolution: 104x212 pixels
- Diagonal Dimension: 2.13"
- Pin Count: 24
- Part #: CFAP400300B10420
- Size: 91mm x 77mm x 1.18mm
- Interfaces: SPI
- Resolution: 400x300 pixels
- Diagonal Dimension: 4.2"
- Pin Count: 24
The Lowest Power LCDs
Our most popular super low power LCD displays draw as little as 1mA and have amazing readability.
- Part #: CFAG12864T3NFH
- Size: 34mm x 24.22mm x 1.75mm
- Interfaces: 8-bit Parallel, SPI
- Resolution: 128x64 pixels
- Color: Dark on Light Gray
- Polarizer: Transflective
- Diagonal Dimension: 1.15"
- Controller: Sitronix ST7565P
- Pin Count: 18
- Part #: CFAG12864U3NFH
- Size: 56mm x 42.5mm x 1.9mm
- Interfaces: 8-bit Parallel, SPI
- Resolution: 128x64 pixels
- Color: Dark on Light Gray
- Polarizer: Transflective
- Diagonal Dimension: 2.23"
- Controller: Sitronix ST7565P
- Pin Count: 18
- Part #: CFAG4265A0TFK
- Size: 22.4mm x 32.85mm x 4.8mm
- Interfaces: SPI
- Resolution: 42x65 pixels
- Color: Dark on White
- Polarizer: Transflective
- Diagonal Dimension: 1.00"
- Backlight: White LED
- Controller: Sitronix ST7565R
- Part #: CFAG240128U0NFH
- Size: 56mm x 42.5mm x 1.9mm
- Interfaces: 8-bit Parallel, I2C, SPI
- Resolution: 240x128 pixels
- Color: Dark on Gray
- Polarizer: Transflective
- Diagonal Dimension: 2.2"
- Controller: Sitronix ST75256P
- Pin Count: 18
Low Power OLED Displays
The beauty of OLED displays and power consumption is that OLEDs only draw current for pixels that are on. For instance, when displaying a black and white checkerboard pattern, an OLED display consumes 50% less current than when displaying a completely white screen. Keeping that in mind, user interfaces can be designed to conserve as much power as possible by limiting how many pixels are lit.
All the OLEDs on this list consume less than 15mA MAX supply current, but have varying voltage requirements.
- Part #: CFAL12896A00127F
- Size: 33.7mm x 26.9mm x 1.6mm
- Interfaces: 8-bit Parallel, SPI
- Resolution: 128x96 pixels
- Color: RGB on Black
- Polarizer: Emissive
- Diagonal Dimension: 1.27"
- Controller: Solomon Systech SSD1351
- Part #: CFAL9664BFB1
- Size: 24.8mm x 22.42mm x 1.42mm
- Interfaces: 8-bit Parallel, SPI
- Resolution: 96x64 pixels
- Color: RGB on Black
- Polarizer: Emissive
- Diagonal Dimension: 0.95"
- Controller: Solomon Systech SSD1332
- Part #: CFAL25664C0021MW
- Size: 80.5mm x 19mm x 1.61mm
- Interfaces: 8-bit Parallel, I2C, SPI
- Resolution: 256x64 pixels
- Diagonal Dimension: 2.08"
- Controller: Solomon Systech SSD1362
- Pin Count: 31
Low Power TFT LCDs
These are our lowest power TFT LCD displays. Even with an LED backlight these full-color TFTs draw very little current.
- Part #: CFAF128128B10145T
- Size: 33.3mm x 38.2mm x 2.8mm
- Interfaces: SPI
- Resolution: 128x128 pixels
- Color: RGB on Dark
- Polarizer: Transmissive
- Diagonal Dimension: 1.45"
- Backlight: White LED
- Controller: Sitronix ST7735S
- Part #: CFAF240320A0024SN
- Size: 42mm x 59mm x 2.1mm
- Interfaces: 16-bit Parallel, 18-bit Parallel, 8-bit Parallel, 9-bit Parallel, DOT-CLK interface / Generic RGB, SPI
- Resolution: 240x320 pixels
- Color: RGB on Black
- Polarizer: Transmissive
- Diagonal Dimension: 2.41"
- Backlight: White LED
- Controller: Sitronix ST7789V
- Pin Count: 40
- Part #: CFAF480640D1035BN
- Size: 64mm x 85mm x 3.1mm
- Interfaces: 16-bit Parallel, 18-bit Parallel, DOT-CLK interface / Generic RGB, SPI
- Resolution: 480x640 pixels
- Color: RGB on Dark
- Polarizer: Transflective
- Diagonal Dimension: 3.5"
- Backlight: White LED
- Controller: Ilitek ILI9806E
- Pin Count: 40
Many Others
Not finding the low-power display you're hoping for? We have hundreds of displays, let us help you find what you're looking for.
