White on Blue 128x64 Parallel Graphic LCDPart Number: CFAG12864M-TMI-TNWhite on Blue 128x64 Graphic LCD with temperature compensation and on-board negative voltage generator.
Resolution: 128x64 pixels
Optics: 6:00 viewing direction
Glass: STN Negative, Transmissive
Controller: Neotec NT7108 (Samsung KS0107/KS0108 Compatible)
Operating Temp:  -20°C to +70°C
Compliance: RoHS Compliant

Order Soon! We only have 9 left!Product VariationsColorsDark on Yellow-Green
Yellow-Green LED BacklightWhite on Blue
White LED Backlight
